Product MarketplaceSoftware & Servers32001409 LoRaWAN™ 915MHz transceiver
ContactSee this Member's ProductsMember Profile
Mipot S.p.a.

32001409 LoRaWAN™ 915MHz transceiver

The 32001409 is a transceiver operating in the 902-928 MHz SRD Band optimized for very long range, low consumption applications, suitable for LPWA networks. The embedded stack is compliant with LoRaWAN Class A and C specification by LoRa Alliance. The module is compliant according to FCC Part 15.212 Modular Transmitter Statement about FCC. Compliant with REACH and RoHS directives, the module meets all the requirements in the industrial temperature range -40/+85°C.

Website

http://www.mipot.com

Documentation

File Details
File type: application/pdf
File size: 801.07 KB

Description

Description

The 32001409 is a transceiver operating in the 902-928 MHz SRD Band optimized for very long range, low consumption applications, suitable for LPWA networks. Based on LoRa RF Technology and LoRaWAN protocol it provides ultra-long range spread spectrum communication and high interference immunity. Thanks to its small LCC form factor (15.5 x 26 mm only) and its low current consumption, this module allows the implementation of highly integrated low power (battery operated) solutions for Internet of Things (IoT) applications, security systems, sensor networks, metering, smart buildings, agriculture, supply chain. This pre-certified solution allows easy integration into final application reducing development time, costs and time-to-market. The embedded stack is compliant with LoRaWAN Class A and C specification by Lora Alliance. Module can be configured via UART interface.
The module meets all the requirements in the industrial temperature range -40/+85°C.
The module is compliant according to FCC Part 15.212 Modular Transmitter Statement about FCC. Compliant with REACH and RoHS directives.

All features of the LoRaWAN can be tested with dedicated evaluation kit (PN 33000162). The board provides easy access to module pin out, power supply pins and SMA antenna connector; usage flexibility is given by several power supply modes. To reduce the time to market and ease the user application SW development, the evaluation kit comes with a built in microcontroller. Access pins on the board allow SW development to be managed by an external microcontroller and custom SW development.
Application

All applications where a long range capability is needed. The module can be used for a large number of Internet of Things (IoT) and Machine to Machine (MtoM) applications, security systems, alarms, sensor networks, metering, smart buildings, agriculture, supply chain, street lighting, fleet tracking, GPS tracking.

Tech Specs

Supported Regional Parameters

    • US902-928

Supported Classes

    • Class A (Basic)
    • Class C

LoRaWAN Specification

    • Old Versions
      • 1.0

Markets

Vertical Markets

    • Smart Agriculture / Farming
    • Smart Buildings / Facilities Management
    • Smart Cities
    • Smart Environment
    • Smart Homes / Neighborhood
    • Smart Industry / Industrial IoT
    • Smart Infrastructure
    • Smart Metering / Smart Utilities
    • Transportation / Logistics / Supply Chain

Regional Markets

    • North America

Regulatory Certifications

    • FCC (United States)

About Mipot S.p.a.

About Mipot S.p.a.

Geographical Focus

  • Europe

Categories

  • Hardware

Vertical Markets

  • Smart Agriculture / Farming
  • Smart Buildings / Facilities Management
  • Smart Cities
  • Smart Environment
  • Smart Homes / Consumer
  • Smart Industry / Industrial IoT
  • Smart Infrastructure
  • Smart Metering / Smart Utilities
  • Transportation / Logistics / Supply Chain

Contacts

Commercial Contact
+39 0481 630200
[email protected]

Technical Contact
[email protected]

Mipot S.p.a.

Website

http://www.mipot.com

View Member Profile
