Wio Tracker 1110 Dev Board-Prototype for Indoor and Outdoor Positioning

Enhance your tracking and environmental monitoring applications with the Wio Tracker 1110 Dev Board - Unleashing indoor and outdoor positioning power through LR1110 and nRF52840 chips, LoRa®, Bluetooth, GPS, and Grove Capabilities. Powered by Nordic nRF52840 and Semtech LR1110.

Website

https://www.seeedstudio.com/

Description

The Wio Tracker 1110 Dev Board is based on Wio-WM1110 Wireless Module and integrates Semtech’s LR1110 LoRa® transceiver and a multi-purpose radio front-end for geolocation, it’s a user-friendly, LoRa-based tracking development platform.

With its compact size and rich Grove interfaces, the Wio Tracker 1110 Dev Board is conveniently equipped with onboard antennas for easy deployment. It supports the Arduino development environment and LoRaWAN® protocol stack, making it ideal for tracking-related IoT projects.

Extended Features

Powered by Nordic nRF52840 and Semtech LR1110
Offers multiple connectivity options including: LoRa®, GNSS(GPS/BeiDou), Bluetooth, Wi-Fi Sniffer
Supports over 300+ Seeed Grove Sensors: making it highly adaptable for different tracking and sensing requirements.
Onboard temperature sensor, humidity sensor, and a 3-axis accelerometer: capturing a wide range of environmental and motion data
Fully Open Source Platform: Leverage the extensive LR1110 and nRF52840 open-source ecosystem for infinite application possibilities.
Arduino IDE compatibility: allowing ease of programming and a familiar environment for developers.

Tech Specs

Supported Regional Parameters

AS923
AU915-928
EU863-870
KR920-923
US915

Environment - IP Rating

Indoor
Other

Supported Classes

Class A (Basic)

LoRaWAN Specification

Current Versions
- 1.0.4

RF Performance Tested

10dBm
12dBm
14dBm
16dBm
18dBm
20dBm

Markets

Vertical Markets

Smart Agriculture / Farming
- Livestock
Smart Cities
- Asset Tracking & Fleet Management

Regional Markets

Africa
Asia/South Pacific
Europe
Middle East
North America
Oceana
South/Latin America
Worldwide

Regulatory Certifications

CE (Europe)
FCC (United States)
