TEKTELIC Communications Inc.
KONA Mega Ex Gateway
Scalable Zone 2/ATEX Rated LoRaWAN® Gateway for Extreme Outdoor Deployments
Website
http://www.tektelic.comDocumentation
LoRa Alliance®
The leading open global standard for secure, carrier-grade IoT LPWAN connectivity.
LoRaWAN® Marketplace
Description
Description
TEKTELIC’s KONA Mega Ex IoT Gateway is Rated IP67 and ATEX/Zone 2 certified, the gateway is designed for the most demanding outdoor installations where combustible gasses, vapours or liquids may be present. It is ideal for public and private network operators that require Full Duplex, multiple Rx and Tx Channels, rugged industrial design and reliable LoRaWAN® gateways to maximise their network investment.<
Extended Features
Extended Features
TEKTELIC’s KONA Mega Ex IoT Gateway is Rated IP67 and ATEX/Zone 2 certified, the gateway is designed for the most demanding outdoor installations where combustible gasses, vapours or liquids may be present. It is ideal for public and private network operators that require Full Duplex, multiple Rx and Tx Channels, rugged industrial design and reliable LoRaWAN® gateways to maximise their network investment.
• ATEX Class 1/Div 2 Deployments
• Pipeline Monitoring
• Mining
• Chemical Production Facilities
• Refineries & Processing Plants
• Commercial Grain Production
Key Product Differentiators
- High availability carrier grade design with support of in-service configuration and software updates
- Certified for ATEX/Zone 2 Classified Deployments
- Full duplex operation making all receive and transmit channels available simultaneously
- Excellent isolation between the Tx and Rx bands as well as out of band rejection of Cellular and Paging networks
- Day-One scalability with support of up to 12 million received messages per day
- Easy to deploy supporting different backhaul and power options
- Fully integrated with the broader eco-system of LoRa® network servers and sensors
Key Features
- Frequency Duplex 72 Rx / 4 Tx
- ATEX/Zone II Certified
- Double Simultaneous Tx Channels
- High Linearity LNA/Receiver
- Integrated Bandpass Filter
- Precise Newtork Synchronization (GPS)
- Integrated GPS Holdover
- 1 Watt (30 dBm) Tx Power
- Geolocalization Support
- Hardened Carrier Grade Enclosure
- Integrated Cellular 3G/4G Modem
- Ethernet Backhaul
- Rated IP67 Enclosure
- All Global ISM Bands
Tech Specs
Supported Regional Parameters
- AS923
- AU915-928
- EU863-870
- US902-928
Markets
Vertical Markets
- Smart Agriculture / Farming
- Smart Cities
- Smart Environment
- Smart Industry / Industrial IoT
- Smart Infrastructure
- Smart Metering / Smart Utilities
Regional Markets
- Europe
- North America
- Worldwide
Regulatory Certifications
- CE (Europe)
- FCC (United States)
- IC (Canada)
About TEKTELIC Communications Inc.
About TEKTELIC Communications Inc.
Geographical Focus
- Worldwide
Categories
- Application server
- End node (sensors or other devices)
- Gateway
- Hardware
- Network server
- Software
- Turnkey Solution
Vertical Markets
- Smart Agriculture / Farming
- Smart Buildings / Facilities Management
- Smart Cities
- Smart Environment
- Smart Homes / Consumer
- Smart Industry / Industrial IoT
- Smart Infrastructure
- Smart Metering / Smart Utilities
- Transportation / Logistics / Supply Chain
