MachineQ, a Comcast Company
Field 64c
64-channel LoRa® Outdoor Gateway
Website
https://www.machineQ.comDocumentation
LoRa Alliance®
The leading open global standard for secure, carrier-grade IoT LPWAN connectivity.
LoRaWAN® Marketplace
Description
Description
Greater Coverage, Fewer Access Points
Gather and transmit data at scale with the MachineQ Field 64c gateway, a high capacity LoRaWAN® gateway for wide-area deployments. The Field 64c includes all of the outdoor-hardening and software features of the Field 16c with 64 channels of LoRaWAN connectivity. Through antenna diversity and optimized RF components, the Field 64c supports hundreds of thousands of connected devices, providing superior scalability.
Features & Capabilities
-
High-availability, carrier-grade design with the support of in-service configuration and software updates
-
Durable in harsh environments, with IP67-rated casing, operational in temperatures that range from -40°C to +55°C
-
Full duplex operation making all receive and transmit channels available simultaneously
-
Excellent isolation between the Tx and Rx bands, as well as out-of- band rejection of Cellular and Paging networks
-
Supports millions of uplinks per day ensuring all sensor data is received and processed
-
Easy to deploy, supporting different backhaul options (Cellular/Ethernet)
-
Fully integrated with the MachineQ platform for seamless operation
Extended Features
Extended Features
TX POWER
2 x 1W (2 x 30 dBm)
POWER
PoE++ (802.3bt)
INTERFACES
Ethernet Backhaul: RJ-45 GPS: N-Type
Cellular Backhaul (3G/4G): N-Type (Optional)
LoRa Antenna (2 parts): N-Type (2nd Port Optional)
CHANNELS
64
CONNECTIVITY
LoRa®, Ethernet, 3G/4G, GPS
DUPLEX
Full
INSTALLATION LOCATION
Outdoor
OPERATING TEMPERATURE
-40°C to +55°C (-40°F to +131°F) at sea level Including solar loading
OPERATIONAL HUMIDITY
10% to 100% condensing
SAFETY
UL 60950-1 (US/C)
REGULATORY
FCC Part 15.247, 109, 209
ETSI EN 300 019-2-1, 300 019-2-2 ETSI EN 300 019-2-3, 300 019-2-4
WHAT’S IN THE BOX
Field 64c
Mounting Bracket
Ethernet Weatherproofing Adapter Internal GPS antenna
Internal Cellular Antenna
SOLD SEPARATELY
PoE Injector
LMR400 Antenna Cable External LoRa® antenna Pole mounting kit
