KNOT LR8G kit – 868 MHz IoT Gateway

An industrial-grade IoT gateway for smart asset tracking, remote monitoring, and efficient automation. The KNOT LR8G kit is the optimal CAT-M/NB-IoT gateway choice for TG-LR82 LoRaWAN sensor nodes in 868 MHz band deployments, as well as for BLE tags such as TG-BT5-OUT.

Website

https://mikrotik.com/

Description

The KNOT LR8G is a compact, out-of-the-box gateway for 868 MHz LoRaWAN-based networks, designed to bring affordable, reliable connectivity to even the most remote or infrastructure-light environments. It supports LTE CAT-M1 and NB2, Bluetooth 5.2, 2.4 GHz Wi-Fi, GPS, and Ethernet with PoE, making it a flexible centrepiece for any IoT deployment.

Extended Features

Operational temperature range -40°C to +70°C
Number of DC inputs 3 (DC jack, PoE-IN, MicroUSB)
DC jack input Voltage 12-57 V
Max power consumption 23 W
Max power consumption without attachments 6 W
PoE in 802.3af/at
PoE in input Voltage 18-57 V
Two 10/100 Ethernet ports
2.4GHz Wi-Fi 4
Bluetooth 5.2 for BLE scanning and advertisement processing
GPS
NanoSIM slot
Indoor use (IP20 rated)
DIN rail mount set included

See for more details: https://help.mikrotik.com/docs/spaces/UM/pages/41680915/RB924i-2nD-BT5+BG77

Markets

Vertical Markets

Smart Agriculture / Farming
Smart Buildings / Facilities Management
Smart Cities
Smart Homes / Neighborhood
Smart Industry / Industrial IoT
Smart Logistics

Regulatory Certifications

CE (Europe)
